| MODEL |
SJ2400DAH |
SJ3000DAH |
SJ3500DAH |
| Process Dimension |
Verarbeitungsmaße (BxHxT) |
2,400X1,220X40T |
3,000X1,220X40T |
3,500X1,220X40T |
| Saw Size |
Hauptsägendurchmesser |
10"~12" |
10"~12" |
10"~12" |
| Power |
Saw(controllable rpm) |
Spindelsäge |
5HP |
7.5HP |
7.5HP |
| Moving to Saw |
Vorwärts- und Rückwärtsbewegung der Spindel |
1HP |
1HP |
1HP |
| Moving Stopper |
adae |
Elektromotor |
Elektromotor |
Elektromotor |
| Chip Colletor |
Staubsammler |
3HP |
5HP |
5HP |
| Stop Function to Make Cutting Size |
Zwischenstopp |
Timer |
Timer |
Timer |
| Safety |
Sicherheitsvorrichtung |
Emergency Stop Button |
Emergency Stop Button |
Emergency Stop Button |
| Meterial |
Upper Plate |
Spitzen |
12T White Bakelite |
12T White Bakelite |
12T White Bakelite |
| Dimension of |
Body |
Körper (BxLxH) |
3,600X2,350X1,650 |
4,300X2,350X1,650 |
4,900X2,350X1,650 |
| Auxiliary Table |
Klappbare Hilfswerkbank (BxL) |
Air Cylinder |
Luftzylinder+Handbuch |
Luftzylinder+Handbuch |
| Electrical Power |
Strom verbraucht |
380V/60Hz(3Ø,4wires) |
380V/60Hz(3Ø,4wires) |
380V/60Hz(3Ø,4wires) |
| Operation |
Arbeitsplatzkontrolle |
OP/S/W |
OP/S/W |
OP/S/W |
| Functions |
Betriebsfunktion |
Auto,Manual |
Auto,Manual |
Auto,Manual |
※ Die Produktspezifikationen variieren je nach Bestellung.
